Switchable Glass

Switchable Glass/Smart Glass -- is a laminated glass product consisting of a Polymer Dispersed Liquid Crystal (PDLC) film sandwiched between two layers of glass and two layers of conductive interlayers. This PDLC film is what allows you to change the visual appearance of the glass from opaque (translucent) to clear (transparent).

PRODUCT PRESENTATION

Description

Switchable Glass/Smart Glass -- is a laminated glass product consisting of a Polymer Dispersed Liquid Crystal (PDLC) film sandwiched between two layers of glass and two layers of conductive interlayers. This PDLC film is what allows you to change the visual appearance of the glass from opaque (translucent) to clear (transparent).

When electricity is applied to the film the liquid crystals line up, changing the glass from opaque to clear. Conversely when electricity is removed, the liquid crystals return to their normal scattered positions changing the glass back to opaque.





Tech specification

Smart glass technique specification
Optical characteristictransmittancePower on≥82%
Power off≤66.8%
HazePower on≤4%
Power off≥96%
View anglePower on>140°
Electrical characteristicOperating voltage  Power on  45V AC
Response timePower on -off
Power off-on
Power consumptionPower on<5W/SQM
General featuresThickness5+5,6+6,8+8,10+10mm
  Largest available size    1.8*3.5m
Working rangeWorking temperature-10ºC-70ºC
Storage temperature-20ºC-80ºC
Working life>10 years
Switch times>100,000
